- Non-Contact Voltage Tester with Wire Stripper
5227Non-Contact Voltage Tester with Wire Stripper
Descriptions:
This product combines most required tools for an electrician to do the wiring job within the building, which includes screwdriver, non-contact voltage detector, illumination and wire stripper for most type wires.
Features:
- With CE Approval.
- CAT IV 1000V
- Illumination
- Replaceable Screwdriver
- Wire Stripper
- Magnet Function
- Sound and Light Indication
- Non-Contact Voltage Detection
Specifications:
MEASUREMENT |
|
|---|---|
| VOLTAGE DETECTION | > 80V AC |
| POWER SOURCE | 3V (AAA 1.5V x 2) |
| WORKING ENVIRONMENT | 0-50°C (32-122°F), <85%RH |
| STORAGE ENVIRONMENT | -20-60°C (-4-140°F), <90%RH |
| CAT CATEGORY | CAT IV 1000V |
| SCREWDRIVER BITS LENGTH | Suggest at least more than 55mm ( 2.16 inch ) |
INSTRUCTION |
|
| 1. NON CONTACT VOLTAGE DETECTION: Please press Non-contact voltage switch to activate the function, the buzzer will beep and sensor indication will light up. When the sensor is near the voltage source which is higher than 80V AC, the buzzer will buzz and indication light will flash. Pressing the Non-contact voltage switch again will deactivate the function, the sensor indication will turn off. CAUTION: If there is no voltage been detected within 3 minutes, the function will automatically power off. |
|
| 2. ILLUMINATION: Press the Illumination switch to activate the function. Press the Illumination switch again will deactivate the function. |
|
WIRE STRIPPER SIZE |
|
 |
|
